DV electronically controlled camera crane
Brand : IDEAL
Product origin : China
Delivery time : 7 days
Supply capacity : 40 set/day
IDEAL-10M130BP-DV
Dv camera jib crane
1.The arm body:Crane Segments 120cm long per section ,3mm thick triangle tube with 130mm*130mm*130mm size,a total of 8 sections
2.Tripod：height about 1.3m
3.High quality dutch head
more than 360 degree rotation,the length of 40 cm,The slowest acuities were 0.5 times/min, fastest 10 times or more per minute,low noise
max loading: 20kg
4.Dutch head controller：start ramp、tilt center、stop ramp、tilt torque、pan center、pan torque、tilt speed、pan speed
5.DV the controller:Can use LACN cameras, cameras with 2.5mm remote interfaces.
6.7 inch monitor and rechargeable battery:The monitor supports the AV signal. If the battery is full, it can be used for 4-5 hours
（1）The power switch（2）220V（ Contact us:Voltage can be replaced according to different countries）（3）DC12V（4）Video channel
7.Wire rope pull：
1、Level of steel wire rope pull 2 sets
2、1 set of vertical wire rope
3、Head 1 set of wire rope
8.The packing box
Big box：1.31m*0.57m*0.4m
Small box：0.81m*0.66m*0.24m
Jib crane for video camera
